Modelo TF2400

Modelo TF2400

The Tamañador MV1 model has a capacity of 1000 kg / hour with 3 levels of Screeners maximum limit, providing four different sizes of seeds. The MV1 tamañadora was intended for those who work with low production and own work. Their plans are fully removable and shakers thanks to its variable speed the operator can have full control of vibration which is appropriate for the different products that work.

Category:
Additional Information
Capacity

3000 kg/hour

Function

Divide the seeds into different sizes.

Longht

3000 mm long and 1570 mm wide and 2800 mm high.

Weight

1300 kg. approx.

Chassis

Made in sheet 3/16. Fixed with possibility of puffing to the surface.

Zaranda

It consists of 2 equal drawers of 1200mm wide x 2400mm long, each containing 2 different sets of squeegees with their respective rubber balls to clean them. It has regulation on the slope and each outlet has its discharge nozzle.

Drive

Three Phase Electric Motor 2 HP.

Feeding

It does not have an accessory for its food but it has a receptive hopper on its upper part.

Download

The discharge is by means of gravity and by 5 discharge nozzles with bags.
