Noria SM

Noria SM

SM La Noria model is used for transporting bulk material by means of chains with rubber blades. This Noria yields between 30/40 T / H approx and manufactured to 17mts long.

It is special for charging silos, trucks, bins and other containers. When working with rubber studs can work with closed angles and that the material does not return.

Category:
Additional Information
Capacity

30/40 tons/hour

Function

To load bulk material

Longht

Weight

Variable

Chassis

2 pipes reinforced structural arms 80mm x 40mm sheaves system for force reduction.

Structure line

: Constituted by rectangular tubes 200 mm x 120 mm reinforced in all its unions. Made completely folded sheet of 2mm and 3.10mm thick.

Transport

Mounted on 1 (one) shaft made of structural pipe of 50 x 50 x 4.76 mm. . with wheels (14, 15 ‘)

Elevation

Through manual winch.

Hauling

A chain with hooks to be bolted rubber blades 185mm. wide x 90 mm. . High

Drive

Three – phase electric motor, hydraulic motor or PTO

Loading and unloading

Punt reception, regulator cover income flow and outlet nozzle.
